BUX™ BMP Battery Powered Magnet with V shaped pole shoes - Clamps, Grabs & Magnets - Lifting, Hoisting and Winching
BUX™ BMP Battery Powered Magnet with V shaped pole shoes
Key Features
- Lift and move heavy flat, round and structrals without restraint.up to 3600 kg
- Handling of loads with poor accessibility (using remote control)
- Hand-held IR remote control unit allows operation from up to 10 metres
- NEW Variable Force Feature – pre-setting of lower magnetic field intensity according to actual need.
- Allows for clamping of single sheet from a whole stack.
Battery Powered BMP Lifting Magnets
Intended Use:
The BMP Battery magnet range is ideal for lifting and transportation of loads up to 3,600 kg - BMP series for Flat, Round and structurals
Unique Control Features:
New variable force feature and tip-off feature allow for quick manipulation, enhanced speed parameters and higher accuracy. Communication with the operator is improved as the battery status can be viewed in offline mode, there is a flat battery indicator in the remote control and sophisticated audiovisual warnings.
Applications:
Used throughout the plant and yard in receiving and shipping areas, cut-off saws, burning tables, and machine tools.
Widespread applications for handling of machined components die blocks, smooth castings, and forgings, plates, bars, pipes and structurals
Features:
• Self-contained lifting magnet
• Handling of loads with poor accessibility (using remote control)
• Hand-held IR remote control unit allows operation from up to 10 meters
• NEW Variable Force Feature – pre-setting of lower magnetic field intensity according to actual need. Allows for clamping of a single sheet from a whole stack.
• Tip-Off Feature – a steady decrease of magnetic force, using the innovative tip-off feature allows gradual release of single sheets from a manipulated bundle.
• BM3600 specifically designed for handling sheets
• UK agents for yearly LOLER compliant testing, service, spares and repair.
• UK Operator training also available
Unique Control Features:
New variable force feature and tip-off feature allow for quick manipulation, enhanced speed parameters and higher accuracy. Communication with the operator is improved as the battery status can be viewed in offline mode, there is a flat battery indicator in the remote control and sophisticated audiovisual warnings
Applications:
Used throughout the plant and yard in receiving and shipping areas, cut-off saws, burning tables, and machine tools.
Widespread applications for handling of machined components die blocks, smooth castings, and forgings, plates, bars, pipes and structurals
BMP series for Flat, Round and structurals
Model |
BMP1800 |
BMP3600 |
|
Workload limit* - Flat material - Round material |
kg kg |
1800 1100 |
3600 2200 |
Length x width of base |
mm |
470 x 242 |
760 x 262 |
Height up to crane hook |
mm |
610 |
620 |
Weight |
kg |
167 |
420 |
*Performance rating on ground 50mm thick S235 JR/AISI 1020 steel plate
