CaRol TS Manual Hand Winches 250-3000kgs
Key Features
- Available in 6 capacities 250, 500, 1000, 1500, 2000 and 3000 kg
- Double braking safety by self-locking wheel and screw system and use of pawl brake with double spring.
- Drum disengageable by easily accessible lever with safety device preventing disengagement when carrying a load
- Variable-length control crank handle (6 adjustment positions) allowing user to either apply maximum control force, or perform rapid cranking for small loads or rewinding.
- Self-locking crank handle adjustment knob for maximum user comfort and safety
Features :
• Complies with machinery directive 98/37/CE.
• Winch satisfies all rupture and endurance test requirements per standard EN13157 :12/2004.
• Drum and gear wheel mounted on bronze bearings.
• Double braking safety by self-locking wheel and screw system and use of pawl brake with double spring.
• Rigid frame with painted mechanical parts and drum.
• Drum disengageable by easily accessible lever with safety device preventing disengagement when carrying a load.
• Users and gears protected by ergonomic cover, removable for maintenance.
• Simple, fast cable fastener.
• Variable-length control crank handle (6 adjustment positions) allowing user to either apply maximum control
force, or perform rapid cranking for small loads or rewinding.
• Self-locking crank handle adjustment knob for maximum user comfort and safety. Allows adjusting crank handle or removing it to prevent operation of winch.
• The TS winch can be secured by 4 points on a vertical mounting plane.
• Easily transportable by a cross bar.
Model
|
CAROL TS 250
|
CAROL TS 500
|
CAROL TS 1000
|
CAROL TS 1500
|
CAROL TS 2000
|
CAROL TS 3000
|
Capacity (kg)
|
250kg
|
500kg
|
1000kg
|
1500kg
|
2000kg
|
3000kg
|
Wire rope diameter (mm)
|
5
|
6.8
|
9
|
11.5
|
13
|
15
|
Max. length wire rope (m)
|
20
|
25
|
35
|
20
|
30
|
40
|
Weight (kg)
|
10
|
15
|
35
|
39
|
61
|
145
|
Winch supplied without wire rope -- To purchase CLICK HERE
