CROSBY IPV(U)Z VERTICAL LIFTING CLAMP (For loads with a small gripping surface)
Key Features
- The IPVZ / IPVUZ beam clamp is used for vertical lift and transfer of angle iron and other loads that have only a small gripping area
- Available in capacities of .75 thru 3.75 metric tonnes
- A wide variety of jaw openings available: 0 to 20 mm
- Welded alloy steel body for strength and smaller size
- Allows for easy connection between the clamp and hoist hook
Delivery Information
Order online for delivery to Mainland UK VAT eligible locations only. Delivery charges will be shown in the shopping cart. Despatch dates for products can vary, if urgent, please contact us. Request a quote for postcodes DD, IV, KW, PA, AB, BT, HS, TR. PO30-PO42, southern Ireland, Channel Islands. For international destinations restrictions may apply.
Returns Policy
Simply email us at sales@dale-lifting.co.uk or call 0161 223 1990 and we will be able to give you a returns authorisation code, which must be sent with the returned item. Returns should be authorised within 14 days from the day of delivery to you. Items should be returned in unused condition & due to the nature of our products a restocking fee may apply. Unfortunately, delivery charges are not refundable. Items returned without an authorisation code may not be accepted. Normally All refunds will be processed within 7- 10 working days on receipt of returned goods.
Non-standard (Quote only, pre-order or custom-made products)
Custom made to order products are not covered by our returns policy. Please ensure when ordering all measurements and capacities are correct as we are unable to refund on these products.
For more information see https://www.dlhonline.co.uk/terms-conditions
CROSBY IPV(U)Z LIFTING CLAMP
The IPVZ / IPVUZ beam clamp is used for vertical lift and transfer of angle iron and other loads that have only a small gripping area for the clamp (“U” has universal hoisting eye). This series of clamps can be used in the vertical and horizontal moving, transfer and stacking of different types of structural designs, such as I-Beams, H-beams, angles, etc, depending on the application desired.
Lifting, transfer and stacking of Steel Beams etc.
- Available in capacities of .75 thru 3.75 metric tonnes.
- A wide variety of jaw openings available: 0 to 28mm.
- Welded alloy steel body for strength and smaller size. Forged alloy components, where required.
- Individually Proof Tested to 2 times the Working Load Limit with certification
- Company name (Crosby IP), logo, Working Load Limit and jaw opening permanently stamped on the body.
- Each product is individually serialised, with the serial number and Proof Load test date stamped on the body. The serial number is included on the test certificate with maintenance and warranty logbook.
- Optional IP-5000 Stinger assembly available. Allows for easy connection between the clamp and hoist hook
- Minimum WLL of 10% of Maximum WLL.• Maintenance replacement parts are available.• Manufactured by an ISO 9001 facility.
- All sizes are RFID EQUIPPED.
| Model |
Working Load Limit (t)* |
Stock No. |
Weight Each (kg.) |
Dimensions (mm) | ||||||||
| Jaw A |
B |
C |
D |
E |
F |
G |
H |
K |
||||
| IPVUZ | 0.75 | 2705146 | 2.3 | 0 - 15 | 45 | 138 | 238 | 30 | 128 | 41 | 37 | 10 |
| IPVUZ | 1.5 | 2705147 | 8.9 | 0 - 20 | 78 | 201 | 378 | 70 | 200 | 61 | 72 | 16 |
| Fixed Hoisting Eye | ||||||||||||
| IPVZ | 0.75 | 2705096 | 2.1 | 0 - 15 | 26 | 128 | 207 | 30 | 115 | 41 | 30 | 10 |
* Design Factor based on EN 13155 and ASME B30.20.
