Donati GBA - 'T' Version - Cantilever Free Standing Jib Cranes upto 2,000 kg capacity
Key Features
- 300° deg slew beam - Laminate T-beam form manually rotated jib cranes
- 125 kg to 2000 kg capacity - Models up to 7 metres reach
- Choice of floor fixings - Surface mounted counter plate or template and foundation bolts
- Optional hoists available
- Underbraced beam - Ideal for low headroom sites
Delivery Information
Order online for delivery to Mainland UK VAT eligible locations only. Delivery charges will be shown in the shopping cart. Despatch dates for products can vary, if urgent, please contact us. Request a quote for postcodes DD, IV, KW, PA, AB, BT, HS, TR. PO30-PO42, southern Ireland, Channel Islands. For international destinations restrictions may apply.
Returns Policy
Simply email us at sales@dale-lifting.co.uk or call 0161 223 1990 and we will be able to give you a returns authorisation code, which must be sent with the returned item. Returns should be authorised within 14 days from the day of delivery to you. Items should be returned in unused condition & due to the nature of our products a restocking fee may apply. Unfortunately, delivery charges are not refundable. Items returned without an authorisation code may not be accepted. Normally All refunds will be processed within 7- 10 working days on receipt of returned goods.
Non-standard (Quote only, pre-order or custom-made products)
Custom made to order products are not covered by our returns policy. Please ensure when ordering all measurements and capacities are correct as we are unable to refund on these products.
For more information see https://www.dlhonline.co.uk/terms-conditions
| Standard Capacity | 63 kg* | 125 kg* | 250 kg* | 500 kg* | 1000 kg* | 2000 kg* |
| Maximum Reach | up to 5.0 metres | up to 7.0 metres | Up to 7.0 metres | Up to 7.0 metres | Up to 6.0 metres | Up to 4.0metres |
| Maximum Height under beam | up to 5.0 metres | up to 6.0 metres | Up to 6.0 metres | Up to 6.0 metres | Up to 6.0 metres | Up to 6.0 metres |
| All models can be supplied with foundation fixings or counter plate for chemical bolt fixings (See below) | ||||||
| * Standard capacities can be de-rated to suit your application | ||||||
Tip: Maximum capacity sizes shown above or view standard models below.
Model features:
300° deg Beam - Laminate T-beam form Manually Rotated Jib Cranes - 125 kg to 2000 kg capacity - Models up to 7 m reach
Suitable for use with standard hoists.
Painted with a base and top coat of yellow enamel, subject to preparation of the surfaces by metallic sandblasting. The drying in a oven concludes the cycle.
Jibs can be supplied with the following options:
- Donati 400V 3ph 50Hz electric chain hoist with single or dual speed and low voltage pendant. Alternatively 110V and 240V electric hoists, other brands, manual or pneumatic hoist are available on request
- Special reach and height
- 400v 3ph. 50 Hz Electric feed system with festooned cables and main/off switch on the column
- Foundation bolts and template or by the addition of an extended counter plate which can be used with chemical anchor fixings in suitable existing concrete floor.
- Mechanical Slewing stops
- Outdoor use
- Special paint finish e.g. Off-shore use
- Installation - Subject to location
Contact our sales team for advice on 0161 223 1990
The Donati jib cranes are designed and manufactured according to the ISO A5 classification.
Download Donati jib crane catalogue for full specifications PDF
Installation and maintenance instructions are provided.
| Lifting Capacity (KG) |
Arm (S) M |
Size of Jib Crane Bracket |
Column | Total Height H (M) | Type | Under Beam h |
Weight Crane (KG) |
Column by m |
| 63 | 4 | A | R | 3 | T30R40 | 2800 | 148 | 18.2 |
| 5 | A | R | 3 | T30R50 | 2800 | 164 | 18.2 | |
| 125 | 2 | A | R | 3 | T30R20 | 2800 | 116 | 18.2 |
| 3 | A | R | 3 | T30R30 | 2800 | 132 | 18.2 | |
| 4 | B | S | 3 | T30S40 | 2760 | 200 | 22.8 | |
| 5 | B | S | 3 | T30S50 | 2760 | 222 | 22.8 | |
| 250 | 2 | B | S | 3 | T30S20 | 2760 | 156 | 22.8 |
| 3 | B | S | 3 | T30S30 | 2760 | 178 | 22.8 | |
| 4 | C | T | 3.5 | T35T40 | 3212 | 320 | 35 | |
| 5 | C | T | 3.5 | T35T50 | 3212 | 351 | 35 | |
| 6 | E | V | 4 | T40V62 | 3640 | 705 | 64 | |
| 7 | E | V | 4 | T40V72 | 3580 | 852 | 64 | |
| 500 | 2 | C | T | 3.5 | T35T20 | 3212 | 260 | 35 |
| 3 | C | T | 3.5 | T35T30 | 3212 | 290 | 35 | |
| 4 | D | U | 3.5 | T35U40 | 3152 | 430 | 43.5 | |
| 5 | D | U | 3.5 | T35U50 | 3152 | 472 | 43.5 | |
| 6 | E | V | 4 | T40V65 | 3580 | 779 | 64 | |
| 6 | F | Z | 4 | T40Z62 | 3580 | 864 | 75.2 | |
| 7 | E | V | 4 | T40V75 | 3540 | 893 | 64 | |
| 7 | F | Z | 4 | T40Z72 | 3540 | 978 | 75.2 | |
| 1000 | 2 | D | U | 3.5 | T35U20 | 3152 | 346 | 43.5 |
| 3 | D | U | 3.5 | T35U30 | 3152 | 388 | 43.5 | |
| 4 | E | V | 4 | T40V40 | 3580 | 678 | 64 | |
| 5 | E | V | 4 | T40V50 | 3580 | 735 | 64 | |
| 6 | F | Z | 4 | T40Z65 | 3540 | 912 | 75.2 | |
| 2000 | 2 | E | V | 4 | T40V20 | 3580 | 564 | 64 |
| 3 | E | V | 4 | T40V30 | 3580 | 621 | 64 | |
| 4 | F | Z | 4 | T40Z40 | 3540 | 780 | 75.2 |
