Load Limiter:

Integral load limiter which automatically prevents overloading of the winch. Load limiter is 100% repeatable at all working pressures and does not wear or generate damaging heat.

Emergency Stop:

Winches can be supplied with an emergency stop device as an option. This shuts off the main air supply to the winch when activated.

Precise Control:

Lever control and pilot pendent control offer variable speed control. Accurate and precise positioning of loads is standard for all models.

Fail-Safe Disc Brake:

The non-asbestos self-adjusting disc brake is applied automatically when the air supply to the winch is shut off. The brake is self-adjusting for the life of the brake and is capable of holding in excess of 125% of the working load limit.

Integral Silencer:

The exhaust air silencer is built into the winch frame and limits the noise level to 80dB(A).

Vane Motor:

Assisted vane lifting ensures maximum starting torque when starting under load.

Sealed Gearbox:

The sealed planetary gearbox ensures that the most stringent duty cycles can be met. The gears are heat treated and mounted on high strength, low friction bearings.

Ease of Maintenance:

The modular design of the winch allows easy access to internal components such as the motor, gearbox, brake, load limiter and drum assembly. Common parts are used throughout the range.
