Pfaff MWS Lifting Hand Winches with Spur Gear Drive
Key Features
- Available from 250 kg to 1500 kg
- Enclosed gear drive for protection of internal parts, even under tough working conditions
- Compact design - Easy and quick mounting onto walls, poles, towers etc.
- Self- locking, back stroke proof, adjustable crank handle for fast lifting of smaller loads
- Automatic load pressure brake for safe holding and extremely sensitive lowering of the load.
Delivery Information
Order online for delivery to Mainland UK VAT eligible locations only. Delivery charges will be shown in the shopping cart. Despatch dates for products can vary, if urgent, please contact us. Request a quote for postcodes DD, IV, KW, PA, AB, BT, HS, TR. PO30-PO42, southern Ireland, Channel Islands. For international destinations restrictions may apply.
Returns Policy
Simply email us at sales@dale-lifting.co.uk or call 0161 223 1990 and we will be able to give you a returns authorisation code, which must be sent with the returned item. Returns should be authorised within 14 days from the day of delivery to you. Items should be returned in unused condition & due to the nature of our products a restocking fee may apply. Unfortunately, delivery charges are not refundable. Items returned without an authorisation code may not be accepted. Normally All refunds will be processed within 7- 10 working days on receipt of returned goods.
Non-standard (Quote only, pre-order or custom-made products)
Custom made to order products are not covered by our returns policy. Please ensure when ordering all measurements and capacities are correct as we are unable to refund on these products.
For more information see https://www.dlhonline.co.uk/terms-conditions
Yale MWS Hand Winches
Manual wire rope winch with spur gear drive
Model MWS Capacities 125 - 1,500 kgs
- Enclosed gear drive for protection of internal parts, even under tough working conditions
- Spur gears on roller bearings, rope drum on plain bearings
- Compact design
- Easy and quick mounting onto walls, poles, towers etc.
- Self- locking, back stroke proof, adjustable crank handle for fast lifting of smaller loads, resulting in lowest possible handle effort and rapid winding of the rope
- Automatic load pressure brake for safe holding and extremely sensitive lowering of the load.
- Unintentional brake release is prevented even with swinging loads
- Suitable for operation in ambient temperatures of -20 through +40 C
- Manufactured in compliance with the German Safety Regulations for Winches, Lifting and Pulling Equipment BGV D8
Optional - Corrosion protected design -Contact us
Winch supplied without wire rope -- To purchase CLICK HERE
| Model | Lifting capacity 1st rope layer kg |
Lifting capacity last rope layer kg |
Crank effort 1st rope layer daN |
Ratio | Recomm. rope diameter mm |
Minimum breaking load of wire rope kN | Useable rope length max. mtr | Number of rope layers max. | Weight without wire rope kg |
| MWS 150 |
150 |
68 |
11 |
1:1 |
4 |
5.7 |
13 |
8 |
4 |
| MWS 300 | 300 | 166 | 6 | 1:7.4 | 5 | 15.9 | 21 | 7 | 10 |
| MWS 600 | 600 | 308 | 10 | 1:7.4 | 6 | 22.9 | 12 | 6 | 11 |
| MWS 1000 | 1000 | 587 | 11 | 1:17 | 9 | 51 | 25 | 5 | 27 |
| MWS 1500 | 1500 | 844 | 12 | 1:25.7 | 10 | 63 | 21 | 5 | 28 |
Applications
Suitable for applications in areas where electric energy is not available or where electric appliances cannot be safely operated on account of mud and dirt.
